    SISIC Silicon Carbide Mechanical Seal For Submersible Sewage Pumps

    mechanical seal SISIC Silicon Carbide Seal Manufacturer of john crane for Submersible Sewage Pumps


    T100,T112,T113,T100S20 Elastomer Bellow to Burgmann MG1/MG12/MG13 mg1-32 Mechanical Seal


    Product name

    High Standard 168 Gasoline Engine Seal Automotive FB Seal Accessories Car for Water Pump Coolant F-12 Yarman

    SizeStandard
    Fit forcar parts/generator engine
    Car MakeCustomizable
    Place of OriginHunan,China(Mainland)
    Brand NameTAKUMI
    MaterialsCustomizable
    Warranty12 Months
    Quality

    100%tested


    Design Structure:Operating limits:
    1. Dependent on the direction of rotation1. Pressure:6bar
    2. Single face2. Temperature-30-200°C
    3. Unbalanced3. Speed: ≤15m/s
    4. Rubber bellows4. Shaft size:10~25.4mm
    5.Sealing face:Silicon carbide,Carbon,TC
    6.Secondary Sealing:FKM,NBR,PTFE,EPDM
    7.Mental component:316L, 304

    Supplier Burgmann MG1 rubber bellow Mechanical Seal for water pump


    1. Sealcon R21 is for Burgmann MG1
    2. Our seals can replace the original seals. we strictly follow DIN24960,ISO3069, EN12756,API628 standards.
    3.If it is not the one you need ,you can pass us your pump model or your drawing ,material,shaft size for quotation.
    we can make whatever mechanical seal you need .
    4.Customized products and OEM is welcomed
    5. We offer Factory Price,High Quality ,Fast Delivery and Best Sevice.


    Product Description

    1) Heat shock stablity

    2) chemical corrosion-resistant

    3) High temper-endure(up to 1650°)

    4) Wearing/corrosion/oxidation resistant

    5) Highly performance of mechanical strength

    6) Cleaning or etching the hardest sub-surfaces

    7) Used for grinding, lapping, and wire saw cutting as well as abrasive blasting


    T100,T112,T113,T100S20 Elastomer Bellow to Burgmann MG1/MG12/MG13 mg1-32 Mechanical Seal


    Operating Conditions


    Pressure:≤1.2MpaDesign feature
    Rotation Speed:≤13m/secRubber belloews structure with big spring
    Temperature:≤-40~150°CSingle structure, better integration and compact construction, reliable seal and long operation cycles
    Uesd in centrifugal pumps, mixer and other rotating equipment
    The mediums are the most general and light chemical duties such as sewage and dirty waterSuitable for many specifiion and designs which conform to ISO3069 and DIN24960

    Material And Component Codes


    DescriptionMaterialMaterial Feature & Suitable Scope

    Rotary /Stationary Face


    Carbon

    Resistant against: erosive heat.

    suitable for water and oil medium.

    Ceramic

    Resistant against:shore hardness,abrasion.

    Suitable for dusted water and oil.

    Silicon Carbide

    Resistant against:heat,abrasion,erosive.

    Suitable for industrial pumps, submersible

    pump sewage pump etc

    Tungsten carbideResistant against:heat,abrasion,erosive.
    Suitable for industrial pumps, submersible
    pump sewage pump etc
    Bellow Cup gasket OringNBR

    Resistant against:pressure,abrasion,high elasticity and mechanical strength.

    Suitable for water and Oil Under -20°C-120°C

    EPDM

    Resistant against:heat freeze,chemical reagent depending.

    Suitable for water and Oil Under -40°C-150°C

    MVQ

    Resistant against:heat, oil, reagent, medicine,

    acetone.Suitable for high temperature.

    Hydraulic equipment and vacum equipment

    Suitable for erosive medium under -20°C-180°C

    ECOResistant against:ozone aging merely ocetum, ammomia ethanol. Suitable for medium -40°C-150°C

    SUS304

    SUS316

    Resistant against: freon, rock oil.

    Suitable for medium -30°C-130°C

    Retainer driver ringspring

    Spring seat

    SUS304

    SUS316

    Resistant against: abrasion, antirust of feature

    SISIC Silicon Carbide Mechanical Seal For Submersible Sewage Pumps


    Superior Raw Materials:


    All the raw materials shall be stored only after the serious inspection and corresponding inspection report.


    Mold:


    Customized mechanical seals can be manufactured according to your samples or drawings


    Inspection:


    Strict QC system to control product quality during whole production.


    Regular inspection shall be conducted on those semi-finished products in the process of producing so as to ensure the scientificness of our technique and the controllability of the inferior products.


    Pre-shipment:


    100% quality control before shipment


    Quality Management:


    The professional Quality Management is the guarantee of your satisfaction for the appearance and specifiion of our products.


    FAQ

    Q: Are you trading company or manufacturer ?

    A: We are professional manufacturer for mechanical seal since 1998.

    Q: How long is your delivery time?

    A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

    Q: Do you provide samples ? is it free or extra ?

    A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

    Q: What is your terms of payment ?

    A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
    If you have another question, pls feel free to contact us.
